Overview

The AAF Rapid Connect service allows the AAF to translate SAML assertions which are verified by a standard Shibboleth SP into JSON Web Token (JWT) which is more suitable for use by services with restricted environments or services with no need to access some of the more advanced parts of the AAF offering.

This document describes JWT for developers and the integration code required to use AAF Rapid Connect with their applications.

The key words "MUST", "MUST NOT", "REQUIRED", "SHALL", "SHALL NOT", "SHOULD", "SHOULD NOT", "RECOMMENDED", "MAY", and "OPTIONAL" in this document are to be interpreted as described in RFC 2119.


JSON Web Token (JWT)

The following is sourced from the JWT specification.

JSON Web Token (JWT) is a compact URL-safe means of representing claims to be transferred between two parties. The claims in a JWT are encoded as a JavaScript Object Notation (JSON) object that is used as the payload of a JSON Web Signature (JWS) structure or as the plaintext of a JSON Web Encryption (JWE) structure, enabling the claims to be digitally signed or MACed and/or encrypted.

The suggested pronunciation of JWT is the same as the English word "jot".

Relationship of JWTs to SAML Assertions

SAML 2.0 provides a standard for creating security tokens with greater expressivity and more security options than supported by JWTs. However, the cost of this flexibility and expressiveness is both size and complexity. SAML's use of XML and XML DSIG contributes to the size of SAML assertions; its use of XML and especially XML Canonicalization contributes to their complexity.

JWTs are intended to provide a simple security token format that is small enough to fit into HTTP headers and query arguments in URIs. It does this by supporting a much simpler token model than SAML and using the JSON object encoding syntax. It also supports securing tokens using Message Authentication Codes (MACs) and digital signatures using a smaller (and less flexible) format than XML DSIG.

Therefore, while JWTs can do some of the things SAML assertions do, JWTs are not intended as a full replacement for SAML assertions, but rather as a token format to be used when ease of implementation or compactness are considerations.

Provided claims

The following claims are provided by AAF Rapid Connect:

Timestamps are defined by the specification as IntDate values, which are: A JSON numeric value representing the number of seconds from 1970-01-01T0:0:0Z UTC until the specified UTC date/time.

Integrating with AAF Rapid Connect

Before you get started

Before you get started with AAF Rapid Connect ensure you MUST meet all of the following high level requirements:

  1. You MUST be using HTTPS on your webserver for all JWT related endpoints. You SHOULD be using HTTPS for your entire application;
  2. The organisation which owns the service you're registering must be an existing AAF subscriber; and
  3. You must have an existing account with AAF connected Identity Provider which you use to access AAF services.

Standard flow

  1. The user accesses your application and is provided access to any public content you wish them to see
  2. When authentication is required users need to be directed to a specific URL within AAF Rapid Connect unique to your application which is provided as part of registration. This can be achieved by:
    1. Presenting the unique URL as a link on your authentication page for the user to click on;
    2. Code within your application provides the user's browser with a 302 response directing the browser to the unique URL.
  3. The user will authenticate to their institution's Identity Provider via their usual means. If the user's IdP is known in advance, it can be specified by appending its entityID to the unique Rapid Connect URL.

     https://rapid.example.com/jwt/authnrequest/auresearch/L4FF32123-YXlnb8w?entityID=https://example.org/idp/shibboleth


    If no entityID is specified, the user will select their Identity Provider from a list of providers at the AAF Discovery Service.

  4. AAF Rapid Connect will validate the user's identity information and generate a unique and signed JWT (JWS) for your application using the secret you define when you register your service
  5. The generated JWT (JWS) will be sent via HTTP POST to the callback endpoint for your application which you define when you register your service.

Create an endpoint for your application to process JWT

AAF Examples

The following AAF developed example code may assist your understanding when writing your own integration code:

Integration Steps

1. Select a JWT library

To get started with AAF Rapid Connect integration select a suitable JWT library from the following for your application. These libraries will assist developers in quickly implementing JWT support. Libraries are not listed in any particular order and not endorsed by us. You should evaluate them individually to determine which best suits your needs. Found a useful JWT library not listed here? Please let us know about it.

Ruby
Java
Python
PHP
Node
.NET
Go
Perl
Haskell
Dart
2. Create a secret

The first step in integrating your code is to compute a secret that will be shared between your applicaition and AAF Rapid Connect for signing and verifying JWT.

Recommended secret generation method on *nix hosts, 32 characters long:

LC_CTYPE=C tr -dc '[[:alnum:][:punct:]]' < /dev/urandom | head -c32 ;echo

This value should never be publicly disclosed. Once created be sure to store it securely. This value will be required during service registration.

3. Provide a web accessible endpoint

Your application MUST define a https endpoint which accepts a HTTP POST request.

The endpoint must acquire the data provided in the parameter assertion for further processing.

4. Validate the signed JWT (JWS) your application has received

Should any stage of the below validation fail your application MUST discard the token and present the user with a suitable error message.

  1. Verify that the signature for the signed JWT you have received is valid by using your locally stored secret value
  2. Ensure that the iss claim has the value https://rapid.aaf.edu.au when in the production environment, or https://rapid.test.aaf.edu.au when in the test environment
  3. Ensure that the aud claim has the value of your application's primary URL (provided as part of service registration)
  4. The current time MUST be after or equal to the the time provided in the nbf claim
  5. The current time MUST be before the time provided in the exp claim
  6. Ensure that the value of the jti claim does not exist in a local storage mechanism of jti claim values you have accepted. If it doesn't (this SHOULD be the case) add the jti claim value to your local storage mechanism for future protection against replay attacks

All applications connecting to the AAF must adhere to all relevant AAF rules and policies. Prior to approving the connection of your service to the federation, the AAF may request to review your JWT related code and test your running endpoint to verify that an application's JWT handling conforms to the above requirements.

5. Make use of the user's personal information

Your application now has a fully verified JWT provided by AAF Rapid Connect.

By looking at the claim https://aaf.edu.au/attributes you will be able to access information about the user which most Research and Scholarly applications require. The following core AAF attributes SHOULD be available:

  1. cn
  2. mail
  3. displayname
  4. edupersontargetedid
  5. edupersonscopedaffiliation

The following optional AAF attributes MAY be available at the discretion of the user's Identity Provider:

  1. edupersonprincipalname: The "NetID" of the person for the purposes of inter-institutional authentication.
  2. givenname: A person's first name or preferred name
  3. surname: A person's surname
  4. edupersonorcid: A person's ORCID identifier, if they have provided one

You can now use this data to create a local account suitable for internal use by your application, for customisation and other purposes. It is RECOMMENDED that you use the data provided in either the JWT claim sub or the https://aaf.edu.au/attributes claim's edupersontargetedid field to uniquely identify users.

The JWT claim sub and the https://aaf.edu.au/attributes claim's edupersontargetedid field are always identical for Rapid Connect. The same value SHALL be provided for all subsequent visits to your application by each user.

The full value of the field must be utilised to ensure your application uniquely identifies the remote user. Applications MUST NOT split this value based on the delimited bang segments.

The value of sub/edupersontargetedid is not able to correlate a user between services. For more details see http://wiki.aaf.edu.au/tech-info/attributes/edupersontargetedid.

Register your service

Access the AAF Rapid Connect website in the production federation or test federation and click on the button for "Register a service" which is on the right hand side in a blue colour under the current version information. At that point you will be asked to select your Identity Provider and authenticate. Once this process is complete you will be returned to the service registration page.

To complete registration please provide:

  1. Organisation - The AAF subscribed organisation which is sponsoring this service.
  2. Name - A descriptive name for your service.
  3. URL - The primary URL of your application which users would enter in the browser to visit your application. This value is provided to your application as the aud claim.
  4. Callback URL - The secure URL within your application that AAF Rapid Connect should POST completed responses to. We described this endpoint as part of the Integration Steps above.
  5. Secret - Must be random and securely stored by the service. This value should never be publicly disclosed and is used by the service to verify signed tokens from AAF Rapid Connect. We generated this as part of the Integration Steps shown above.

If you're registering in the production federation

Once submitted the AAF will review and contact you with any questions. You should expect a response via email within 2 business days which will include a unique URL within AAF Rapid Connect for your application to start the authentication process as we discussed in Standard Flow above.

If you're registering in the test federation

Your application will be automatically approved. The completion screen will show the unique URL for your application to initiate login. You can use this immediently with your application to start the authentication process as we discussed in Standard Flow above.

Buttons

The AAF provides buttons in several sizes which your application should use to let your users know they can login via the AAF. These buttons are used in marketing and help documentation which is provided to end user support desks and makes the process of logging in seem familiar for users across multiple applications.

You may hotlink or rehost these images. Please use in accordance with the AAF logo use policy (PDF).

110x26
AAF tiny login

223x54
AAF tiny login

439x105
AAF tiny login

866x193
AAF tiny login

Help

To get help with AAF Rapid Connect simply email AAF support on support@aaf.edu.au
